Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2

Klantenoverzichten
Wij bezochten hun fabriek vaak. Hun workshop is zeer groot en e-de module van de inktvertoning is werkelijk groot!

—— Chris

Ons bedrijf heeft orden aan Ridafone vaak geplaatst. Zij ontwikkelen en veroorzaken alle e-inktlcd weergavemappen in goede kwaliteit.

—— Picado Freddy

Ik ben online Chatten Nu

Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2

Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2
Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2 Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2 Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2 Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2 Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2 Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2

Grote Afbeelding :  Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2

Productdetails:
Plaats van herkomst: Taiwan
Merknaam: innolux
Certificering: Rohs,CE,FCC
Modelnummer: M280DGJ-L30
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 10PCS
Prijs: Negotiation
Verpakking Details: Industriële verpakking
Levertijd: 4-5 werkdag
Betalingscondities: T/T, W, Western Union, MoneyGram
Levering vermogen: 3000pcs per week

Laptop van 3840*2160 Innolux 28Inch Lcd Monitor M280DGJ-L30 300cd/M2

beschrijving
Kwaliteit: Gloednieuwe Origineel Pakket: Originele industriële verpakking
Materiaal: het glas oled Kleur: 16.7M kleuren
Model: WLED Stijl: brede het scherm hoge resolutie 3840*2160
Helderheid: 300cd Schakelaar: 30PIN
Contrastverhouding: 1600:1 Beroepsleven: 30k uren
Hoog licht:

3840*2160 Laptop Lcd Monitor

,

Laptop van Innolux 28Inch Lcd Monitor

,

M280DGJ-L30

3840*2160 Pixels innolux 28Inch laptop lcd monitor M280DGJ-L30 300 cd/m² (Typ.) 1000:1 51pin 12V 30k hours WLED



Innolux Corporation (hereafter called Innolux) M280DGJ-L30 is a 28.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: WLED Backlight, Reverse I/F, 10 bit, Matte, G-Sync / FreeSync , Energy Star 7.0 Compliance, Gsync/Freesync. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q3, 2013, Now this model is in production.  We inputted this model's specification on Aug 15 2013 for the first time, and the latest update on Jul 7 2020. If you want to embed M280DGJ-L30 LCM in your future product,einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The M280DGJ-L30 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.





Brand
Diagonal Size
Pixel Format
Active Area
Bezel Area
Luminance
View Direction
Viewing Angle
Support Color
Weight
Frame Rate
Innolux
28.0 inch
3840(RGB)×2160 [UHD] 157PPI
620.93(H)×341.28(V) mm
626.93(H)×347.28(V) mm
300 cd/m² (Typ.)
6 o'clock
85/85/80/80 (Typ.)(CR≥10)
1.07B 72% NTSC
2.91/3.10Kgs (Typ./Max.)
60Hz
Model
Type
Configuration
Outline Dim.
Treatment
Contrast Ratio
Response Time
Operating Mode
Light Source
Designed For
Touch Panel
M280DGJ-L30
a-Si TFT-LCD , LCM
RGB Vertical Stripe
648.9(H)×369.3(V) ×20.85(D) mm
Antiglare (Haze 25%), Hard coating (3H)
1000:1 (Typ.) (TM)
1.5/3.5 (Typ.)(Tr/Td)
TN, Normally White, Transmissive
WLED [4 strings] , 30K hours , W/O Driver
Without
Interface Type V-by-One 8 lane 51 pins Connector
Power Supply 12.0V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
