AUO 32inch industrial & Medical Imaging LCD Panel G320ZAN02.3 3840*2160Pixels 137ppi 51pin 12V outdoor high brightness

Merknaam:	AUO
Modelnummer:	G320ZAN02.3
MOQ:	10 STUKS
Prijs:	USD120/PC
Verpakking:	Industriële verpakking
Betalingsvoorwaarden:	T/T, W, Western Union, MoneyGram

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Certificering:

Rohs,CE,FCC

Kwaliteit:

Gloednieuw origineel

Pakket:

Originele industriële verpakking

Materiaal:

het glas oled

Kleur:

1.06b kleuren

Model:

Stijl:

breed scherm met hoge resolutie 1024*768PIXELS

Helderheid:

850cd

Connector:

51pin

Contrastverhouding:

1500:1

Werktijd:

30k uur

Schermgrootte:

32 inch

Levering vermogen:

3000 pcs per week

Productbeschrijving

AUO 32inch industrial & Medical Imaging LCD Panel G320ZAN02.3 3840*2160Pixels 137ppi 51pin 12V outdoor high brightness

AU Optronics Corp. (hereafter called AUO) G320ZAN02.3 is a 32.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by einklcd in the following: DCI-P3, Adobe RGB, sRGB, Hight Brightness, WLED Backlight, With LED Driver, 10 bit, Glossy , 98% DCI-P3, 99 Adobe RGB. Based on its features, einklcd recommend that this model be applied to Industrial, Medical Imaging, Outdoor High Brightness etc. According to the information stored in einklcd this model mass production on Q2, 2023, Now this model is in production. We inputted this model's specification on Oct 9 2025 for the first time. If you want to embed G320ZAN02.3 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The G320ZAN02.3 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:AUO

Model P/N: G320ZAN02.3

Diagonal Size: 32.0"

Panel Type: a-Si TFT-LCD, LCM

Resolution: 3840(RGB)×2160, UHD 137PPI

Pixel Format: RGB Vertical Stripe

Active Area 708.48(W)×398.52(H) mm

Bezel Opening 714.48(W)×404.52(H) mm

Outline Size: 727.3(W)×424.5(H) ×20.98(D) mm

Brightness: 850 cd/m² (Typ.)

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Best View on Symmetry

Display Colors: 1.07B 98% DCI-P3

Frequency: 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Weight: 4.63Kgs (Typ.)

Surface Glare (Haze 0%)

Contrast Ratio: 1500:1 (Typ.) (TM)

Display Mode :AHVA, Normally Black, Transmissive ,IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Response Time: 10/10 (Typ.)(Tr/Td)

Lamp Type: WLED , 30K hours , With LED Driver

Touch Screen:Without

Application:Industrial Medical Imaging Outdoor High Brightness

Signal Interface eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector

Input Voltage :12.0V (Typ.)

Environment Operating Temp.: 0 ~ 50 °C ;

Storage Temp.: -20 ~ 60 °C
