BOE GV215FHM-N10 21.5 Inch Industrial LCD Panel with 1920x1080 Pixels 450cd/m2 Brightness and 30pin Connector for Digital Signage

Merknaam:	BOE
Modelnummer:	GV215FHM-10
MOQ:	10 STUKS
Prijs:	negotiable
Betalingsvoorwaarden:	T/T,W,Western Union,MoneyGram
Leveringscapaciteit:	3000 pcs per week

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

Japan

Certificering:

Rohs,CE,FCC

Kwaliteit:

Gloednieuw origineel

Pakket:

Originele industriële verpakking

Oplossing:

1920*1080pixels

Stijl:

30PIN IPS

Helderheid:

450cd/m2

Kleur:

16,7 miljoen

Contrastverhouding:

900:1

werkende leven:

50k uur

Type:

Lcm

Maat:

21,5 inch

Lamptype:

Lcm

Spanning:

5.0v

modelnummer:

GV215FHM-N10

Verpakking Details:

Industriële verpakking

Markeren:

1920x1080 Pixels Industrial LCD Panel

450cd/m2 Brightness TFT-LCD Display

30pin Connector LCM

Productbeschrijving

BOE GV215FHM-N10 21.5-Inch Industrial LCD Panel

GV215FHM-N10 is a 21.5-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring an integrated WLED backlight system. This industrial-grade panel is designed for demanding applications with an operating temperature range of -20°C to 70°C and maximal vibration level of 1.05G (10.3 m/s²).

Key Features

21.5-inch diagonal display with 1920*1080 FHD resolution
High brightness: 450 cd/m² typical
Wide viewing angle: 89/89/89/89 (CR≥10)
WLED backlight with 50,000 hours lifespan
Industrial operating temperature: -20°C to 70°C
Landscape/Portrait orientation support
Matte surface with anti-glare treatment
High temperature nematic liquid crystal (105°C)

Technical Specifications

Brand	BOE
Model P/N	GV215FHM-N10
Diagonal Size	21.5"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)*1080, FHD (102 PPI)
Active Area	476.64(W)*268.11(H) mm
Outline Dimensions	485.6(W)292.2(H)11.2(D) mm
Luminance	450 cd/m² (Typical)
Contrast Ratio	1000:1 (Typical)
Viewing Angle	89/89/89/89 (CR≥10)
Response Time	14 ms (G to G, Typical)
Color Depth	16.7M colors
Refresh Rate	60Hz
Signal Type	LVDS (2 ch, 8-bit), 30-pin connector
Voltage Supply	5.0V (Typical)
Mass	1.93 kg (Typical)
Touchscreen	Without

Environmental Specifications

Operating Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C
Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)

Application Areas

This industrial LCD panel is recommended for Industrial applications, Digital Signage, and other demanding environments requiring reliable performance across wide temperature ranges.

Production Status Note: This model entered mass production in Q4 2022 and is currently in production. For the latest production status and specification details, we strongly recommend contacting BOE or their authorized agents before integrating this LCM into your products.
