details van de producten

Created with Pixso. Thuis Created with Pixso. Producten Created with Pixso.
Autolcd Vertoning
Created with Pixso.

BOE 10.1inch Car LCD Display with 1000 cd/m² Brightness 1280*720 Pixels and 60pin Connector for Outdoor Applications

BOE 10.1inch Car LCD Display with 1000 cd/m² Brightness 1280*720 Pixels and 60pin Connector for Outdoor Applications

BOE 10.1inch Car LCD Display with 1000 cd/m² Brightness 1280*720 Pixels and 60pin Connector for Outdoor Applications

Merknaam: BOE
Modelnummer: AV101HDM-N10-28P2
MOQ: 10 STUKS
Prijs: negotiable
Betalingsvoorwaarden: T/T,W,Western Union,MoneyGram
Leveringscapaciteit: 3000 pcs per week
Gedetailleerde informatie
Productbeschrijving
Gedetailleerde informatie
Plaats van herkomst:
China
Certificering:
Rohs,CE,FCC
Kwaliteit:
Gloednieuw origineel
Pakket:
Originele industriële verpakking
Oplossing:
1280 x 720 pixels
Stijl:
Lcm
Helderheid:
1000 CCD-M2
Kleur:
16,7 miljoen
Contrastverhouding:
1000 :1
werkende leven:
50k uur
Connector:
60pin
Verpakking Details:
Industriële verpakking
Markeren:

1000 cd/m² Brightness Car LCD Display

,

1280*720 Pixels TFT-LCD Display

,

60pin Connector LCM Display

Productbeschrijving
BOE 10.1-inch Car LCD Display
High-brightness 1280*720 pixel automotive display with 1000 cd/m² brightness and 60-pin connector, designed for outdoor high-brightness applications.
Product Overview
The AV101HDM-N10-28P2 is a 10.1-inch diagonal a-Si TFT-LCD display panel from BOE Technology Group Co., Ltd., featuring an integral WLED backlight system. This display operates within a wide temperature range of -30°C to 85°C and is engineered for demanding automotive and outdoor environments.
Key Features
  • 10.1-inch diagonal display with 1280*720 resolution
  • Ultra-high brightness: 1000 cd/m² typical
  • Wide operating temperature: -30°C to 85°C
  • WLED backlight with 50,000+ hour lifespan
  • LVDS interface with 60-pin connector
  • sRGB color gamut with 86% NTSC coverage
  • Designed for automotive and outdoor applications
Technical Specifications
Model NumberAV101HDM-N10-28P2
Panel Typea-Si TFT-LCD, LCM
Resolution1280(RGB)*720 (WXGA), 145 PPI
Active Area223.68*125.82 mm
Brightness1000 cd/m² (Typical)
Contrast Ratio1000:1 (Typical)
Viewing Angle85/85/85/85 (CR≥10)
Response Time30 ms maximum (Tr+Td)
InterfaceLVDS (1 channel, 8-bit), 60-pin connector
Power Supply3.3V typical
Operating Temperature-30°C to 85°C
Storage Temperature-40°C to 90°C
Touch PanelWithout touch screen
Application Areas
This high-brightness display is specifically designed for outdoor high-brightness applications and automotive display systems where visibility in direct sunlight is critical.
Note: Production status and specifications are subject to change. Please contact BOE or their authorized agents for the latest production and specification details before integrating this display into your products.
