27 Inch CSOT Desktop Monitor Module with 1920×1080 Resolution 250CD/M2 Brightness and 144Hz Refresh Rate

Name: 27 Inch CSOT Desktop Monitor Module with 1920×1080 Resolution 250CD/M2 Brightness and 144Hz Refresh Rate
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: SG2701B08-1
Price: 30.00 USD
Availability: InStock

Merknaam:	Innolux
Modelnummer:	SG2701B08-1
MOQ:	10 STUKS
Prijs:	negotiable
Betalingsvoorwaarden:	T/T,W,Western Union,MoneyGram
Leveringscapaciteit:	3000 pcs per week

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Certificering:

Rohs,CE,FCC

Kwaliteit:

Gloednieuw origineel

pakket:

Originele industriële verpakking

brightnerss:

250cd/m2

Connector:

30PIN

Kleur:

16,7 miljoen

Contrastverhouding:

1500:1

werkende leven:

30.000 uur

Oplossing:

1920*1080pixels

Spanningsvoorziening:

5.0v

Signaaltype:

LVDS

Verpakking Details:

Industriële verpakking

Productbeschrijving

27 Inch CSOT LVDS Desktop Monitor Module SG2701B08-1

Product Overview

27-inch CSOT LVDS desktop monitor module featuring 1920×1080 resolution, 81ppi pixel density, and 250 cd/m² brightness. This SG2701B08-1 Ver.7.1 model is a 27.0" diagonal a-Si TFT-LCD display panel from China Star Optoelectronics Technology Co., Ltd (CSOT).

Key Specifications

Brand	CSOT
Model Number	SG2701B08-1 Ver.7.1
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	1920(RGB)×1080 (FHD), 81PPI
Active Area	597.888 × 336.312 mm
Outline Dimensions	608.888 × 347.312 × 1.3 mm (H×V×D)
Refresh Rate	144Hz
Contrast Ratio	1500:1 (Typical)
Response Time	14ms (Typical, G to G)
Viewing Angle	89/89/89/89 (Typical, CR≥10)
Color Depth	16.7M colors, 99% sRGB
Signal Type	LVDS (2 ch, 8-bit), 30 pins Connector
Operating Voltage	5.0V (Typical)

Technical Features

Work Mode	IPS, Normally Black, Transmissive
Surface Treatment	Antiglare (Haze 25%), Hard coating (3H)
Glass Thickness	0.50+0.50 mm
Transmissivity	6.4% (Typical, with Polarizer)
Driver IC	Built-in COF 6 source chips
Weight	680g (Typical)
Backlight	No backlight included
Touchscreen	Without touch screen

Environmental Specifications

Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Note: This model is recommended for desktop monitor applications. Mass production is scheduled for Q3 2025, and the model is currently in production. For the latest production status and specification details, please contact CSOT or their authorized agents directly.
